碳化硅 MOSFET

APS自主研发的碳化硅MOSFET 具备高开关频率，低导通电阻，优良高温特性，与耐高压等优势，有着替代现有IGBT和超结MOSFET的巨大潜力。其应用在更高频率的电源设计里，能够缩小系统储能器件的体积，例如大电感，大变压器及大容量电容等，从而降低系统成本。

APS推出的第二代平面结构MOSFET促进了光伏风电，新能源汽车车，不间断电源，服务器电源等应用往高效与高可靠性发展的趋势。已有的封装类型包括：TO247-3、TO247-4等。

Part Number	Generation	Qualification	Blocking Voltage V_DC	R_DS(_on)	Recommended V_GS	Current Rating	Total Gate Charge	P_D(T_J=25℃)	Package	Release Schedule	Recommended for New Design?
A3M014F120QAN	Gen 3	Automotive	1200 V	14 mΩ	15 V	135 A	277 nC	682 W	TO247-4		Yes
A3M018F120QAN	Gen 3	Automotive	1200 V	18 mΩ	15 V	123 A	227 nC	536 W	TO247-4		Yes
A3M040F120QNN	Gen 3	Industrial	1200 V	40 mΩ	15 V	50 A	99 nC	230 W	TO247-4		Yes
A3M080F120QAN	Gen 3	Automotive	1200 V	80 mΩ	15 V	29 A	51 nC	160 W	TO247-4		Yes
A3M011F075HAN	Gen 3	Automotive	750 V	11mΩ	15 V	170 A	270 nC	672 W	TO263-7		Yes
ACM800P170HNN	Gen 2+	Industrial	1700 V	800 mΩ	20 V	5.3 A	19 nC	52 W	TO263-7	2024Q1	Yes
ACM800P170BNN	Gen 2+	Industrial	1700 V	800 mΩ	20 V	5.5 A	19 nC	55 W	TO247-3	2024Q1	Yes
ACM018P120QNN	Gen 2+	Industrial	1200 V	18 mΩ	20 V	105 A	230 nC	428 W	TO247-4	Available	Yes
ACM035P120QNN	Gen 2+	Industrial	1200 V	35 mΩ	20 V	69 A	136 nC	300 W	TO247-4	Available	Yes
ACM035P120QSN	Gen 2+	Solar	1200 V	35 mΩ	20 V	69 A	136 nC	300 W	TO247-4	Available	Yes
ACM070P120QNN	Gen 2+	Industrial	1200 V	70 mΩ	20 V	39 A	72 nC	200 W	TO247-4	Available	Yes
ACM035P120QAN	Gen 2	Solar	1200 V	35 mΩ	20 V	69 A	136 nC	330 W	TO247-4	Available	Yes
ACM070P120QAN	Gen 2+	Automotive	1200 V	70 mΩ	20 V	39 A	72 nC	200 W	TO247-4	Available	Yes
ACM160P120QAN	Gen 2+	Automotive	1200 V	160 mΩ	20 V	19 A	32 nC	120 W	TO247-4	Available	Yes
ACM160P120BNN	Gen 2+	Industrial	1200 V	160 mΩ	20 V	19 A	32 nC	120 W	TO247-3	Available	Yes
ACM035P120BNN	Gen 2+	Industrial	1200 V	35 mΩ	20 V	69 A	136 nC	330 W	TO247-3	Available	Yes
ACM070P120BNN	Gen 2+	Industrial	1200 V	70 mΩ	20 V	39 A	72 nC	200 W	TO247-3	Available	Yes
ACM035P120HAN	Gen 2+	Automotive	1200 V	35 mΩ	20 V	69 A	136 nC	300 W	TO263-7	Available	Yes
ACM160P120HANB	Gen 2+	Automotive	1200 V	160 mΩ	20 V	19 A	32 nC	120 W	TO263-7	Available	Yes
ACM070P120HAN	Gen 2+	Automotive	1200 V	70 mΩ	20 V	39 A	72 nC	200 W	TO263-7	Available	Yes
ACM045F065QANC	Gen 2++	Automotive	650 V	45 mΩ	15 V	51 A	79 nC	200 W	TO247-4	Available	Yes
ACM030F065QANC	Gen 2++	Automotive	650 V	30 mΩ	15 V	70 A	111 nC	246 W	TO247-4	Available	Yes
ACM060F065QANC	Gen 2++	Automotive	650 V	60 mΩ	15 V	42 A	176 nC	59 W	TO247-4	Available	Yes
ACM045F065QNNC	Gen 2++	Automotive	650 V	45 mΩ	15 V	51 A	79 nC	200 W	TO247-4	Available	Yes
ACM030F065QNNC	Gen 2++	Industrial	650 V	30 mΩ	15 V	70 A	111 nC	246 W	TO247-4	Available	Yes
ACM060F065QNNC	Gen 2++	Industrial	650 V	60 mΩ	15 V	42 A	176 nC	59 W	TO247-4	Available	Yes
ACM030F065LNNC	Gen 2++	Industrial	650 V	30 mΩ	15 V	TBD	TBD	TBD	TOLL	Available	Yes
ACM045F065LNNC	Gen 2++	Industrial	650 V	45 mΩ	15 V	TBD	TBD	TBD	TOLL	Available	Yes
ACM040P120Q	Gen 2	Industrial	1200 V	40 mΩ	20 V	64 A	146 nC	300 W	TO247-4	Available	No
ACM040P120B	Gen 2	Industrial	1200 V	40 mΩ	20 V	64 A	146 nC	300 W	TO247-3	Available	No
ACM060L065Q	Gen 2	Industrial	650 V	60 mΩ	18 V	48 A	78 nC	176 W	TO247-4	Available	No
ACM030LS065L	Gen 2	Industrial	650 V	30 mΩ	18 V	88 A	163 nC	263 W	TOLL	Available	No
