碳化硅二极管-飞锃半导体(上海)有限公司

Part Number	Generation	Qualification	V_DC	I_F(T_C=150℃)	V_F (T_J=25℃) Typical	Maximum continuous Current	Total Power Dissipation	Total Capacitive Charge	I_R(T_J=25℃) Max	Package	Recommended for New Design?	Release Schedule
A4D50PS120AN	Gen 4	Industrial	1200 V	50 A	TBD	TBD	TBD	TBD	TBD	TO247-2	Yes	2024Q1
A3D20PS170AN	Gen 3	Industrial	1700 V	20 A	1.45 V	54A	333 W	200nC	150µA	TO247-2	Yes	Available
A3D30PD170AN	Gen 3	Industrial	1700 V	30 A	1.50 V	74A	455 W	275nC	150µA	TO247-2	Yes	Available
A3D20PA120AN	Gen 3	Industrial	1200 V	20 A	1.40 V	58A	250 W	93nC	200µA	TO247-2	Yes	Available
ACD20PS120A	Gen 3	Industrial	1200 V	20 A	1.45 V	58A	250 W	93nC	200µA	TO247-2	Yes	Available
A3D30PA120AN	Gen 3	Industrial	1200 V	30 A	1.40 V	80A	405 W	152nC	200µA	TO247-2	Yes	Available
ACD20PS120ANX	Gen 3	Industrial	1200 V	20 A	1.45 V	58A	250 W	93nC	200µA	TO247-2	Yes	Available
ACD30PS120ANX	Gen 3	Industrial	1200 V	30 A	1.45 V	80A	330 W	158nC	200µA	TO247-2	Yes	Available
ACD30PS120A	Gen 3	Industrial	1200 V	30 A	1.45 V	80A	330 W	158nC	200µA	TO247-2	Yes	Available
A3D40PB120AN	Gen 3	Industrial	1200 V	40 A	1.45 V	115A	536 W	93nC	200µA	TO247-2	Yes	Available
ACD40PD120B	Gen 3	Industrial	1200 V	40 A	1.45 V	110A (per leg/per device)	430 W	93nC	200µA	TO247-3	Yes	Available
A3D40PB120BN	Gen 3	Industrial	1200 V	40 A	1.45 V	110A (per leg/per device)	577 W	93nC	200µA	TO247-3	Yes	Available
ACD50PD120A	Gen 3	Industrial	1200 V	50 A	1.40 V	155A	625 W	310nC	200µA	TO247-2	Yes	Available
A3D20PS120ANB	Gen 3+	Industrial	1200 V	20 A	1.35 V	58A	250 W	93nC	200µA	TO247-2	Yes	Available
A3D20PA120ANB	Gen 3+	Industrial	1200 V	20 A	1.35 V	58A	250 W	93nC	200µA	TO247-2	Yes	Available
A3D30PS120ANB	Gen 3	Industrial	1200 V	30 A	1.35 V	80A	330 W	135nC	200µA	TO247-2	Yes	Available
A3D30PA120ANB	Gen 3	Industrial	1200 V	30 A	1.35 V	80A	330 W	135nC	200µA	TO247-2	Yes	Available
ACD30PS090A	Gen 3	Industrial	900 V	30 A	1.45 V	80A	200 W	101nC	150µA	TO247-2	No	Available
A3D42PA090AN	Gen 3	Industrial	900 V	42 A	1.40 V	105A	250 W	145nC	150µA	TO247-2	Yes	Available
ACD06PS065G	Gen 3	Industrial	650 V	6 A	1.45 V	18A	68 W	15nC	80µA	DFN 8x8	Yes	Available
ACD06PS065E	Gen 3	Industrial	650 V	6 A	1.45 V	18A	68 W	15nC	80µA	TO263-2	Yes	Available
A3D04PS065NN	Gen 3	Industrial	650 V	4 A	1.40 V	11A	47 W	11nC	80µA	DFN 5x6	Yes	Available
ACD06PS065T	Gen 3	Industrial	650 V	6 A	1.45 V	18A	68 W	15nC	80µA	TO220F	Yes	Available
ACD06PS065N	Gen 3	Industrial	650 V	6 A	1.45 V	18A	68 W	15nC	80µA	DFN 5x6	Yes	Available
ACD10PS065E	Gen 3	Industrial	650 V	10 A	1.45 V	32A	94 W	23nC	80µA	TO263-2	Yes	Available
ACD10PS065C	Gen 3	Industrial	650 V	10 A	1.45 V	32A	94 W	23nC	80µA	TO220-2	Yes	Available
A5D20PS065CN	Gen 5	Industrial	650 V	20 A	1.45 V	43A	166 W	42nC	50µA	TO220-2	Yes	Available
ACD04HS065F	Gen 3	Industrial	650 V	4 A	1.25 V	20A	65 W	15nC	80µA	TO252-2	Yes	Available
ACD04PS065G	Gen 3	Industrial	650 V	4 A	1.40 V	11A	47 W	11nC	80µA	DFN 8x8	Yes	Available
A5D10PS065CN	Gen 5	Industrial	650 V	10 A	1.45 V	23A	100 W	21nC	50µA	TO220-2	Yes	Available
ACD10PS065G	Gen 3	Industrial	650 V	10 A	1.45 V	32A	94 W	23nC	80µA	DFN 8x8	Yes	Available
A5D06PS065FN	Gen 5	Industrial	650 V	6 A	1.45 V	15A	60 W	14nC	30µA	TO252-2	Yes	Available
A5D10PS065TN	Gen 5	Industrial	650 V	10 A	1.45 V	23A	100 W	21nC	50µA	TO220F	Yes	Available
ACD10PS065T	Gen 3	Industrial	650 V	10 A	1.45 V	32A	94 W	23nC	80µA	TO220F	Yes	Available
A5D06PS065CN	Gen 5	Industrial	650 V	6 A	1.45 V	15A	60 W	14nC	30µA	TO220-2	Yes	Available
A5D06PS065TN	Gen 5	Industrial	650 V	6 A	1.45 V	15A	60 W	14nC	30µA	TO220F	Yes	Available
ACD06PS065F	Gen 3	Industrial	650 V	6 A	1.45 V	18A	68 W	15nC	80µA	TO252-2	Yes	Available
A5D08HS065CN	Gen 5	Industrial	650 V	8 A	1.35 V	23A	100 W	21nC	30µA	TO220-2	Yes	Available
A3D08HS065C	Gen 3	Industrial	650 V	8 A	1.35 V	32A	94 W	23nC	80µA	TO220-2	Yes	Available
ACD08PS065C	Gen 3	Industrial	650 V	8 A	1.40 V	32A	94 W	23nC	80µA	TO220-2	Yes	Available
ACD15PS065C	Gen 3	Industrial	650 V	15 A	1.45 V	37A	136 W	34nC	80µA	TO220-2	Yes	Available
A5D10PS065AN	Gen 5	Industrial	650 V	10 A	1.45 V	23A	100 W	21nC	50µA	TO247-2	Yes	Available
A5D10PS065EN	Gen 5	Industrial	650 V	10 A	1.45 V	23A	100 W	21nC	50µA	TO263-2	Yes	Available
A5D10PS065FN	Gen 5	Industrial	650 V	10 A	1.45 V	23A	100 W	21nC	50µA	TO252-2	Yes	Available
ACD06PS065C	Gen 3	Industrial	650 V	6 A	1.45 V	18A	68 W	15nC	80µA	TO220-2	Yes	Available
ACD40PS065A	Gen 3	Industrial	650 V	40 A	1.45 V	80A	250 W	85nC	80µA	TO247-2	Yes	Available
ACD10PS065F	Gen 3	Industrial	650 V	10 A	1.45 V	32A	94 W	23nC	80µA	TO252-2	Yes	Available
ACD10PS065A	Gen 3	Industrial	650 V	10 A	1.45 V	32A	94 W	23nC	80µA	TO247-2	Yes	Available
A5D20PD065BN	Gen 5	Industrial	650 V	20 A	1.45 V	46A (per leg/per device)	200 W	21nC	50µA	TO247-3	Yes	Available
A5D40PD065BN	Gen 5	Industrial	650 V	40 A	1.45 V	86A (per leg/per device)	332 W	42nC	50µA	TO247-3	Yes	Available
ACD10HS065A	Gen 3	Industrial	650 V	10 A	1.25 V	37A	136 W	34nC	80µA	TO247-2	Yes	Available
ACD20HD065B	Gen 3	Industrial	650 V	20 A	1.25 V	70A (per leg/per device)	230 W	34nC	80µA	TO247-3	Yes	Available
ACD40PD065B	Gen 3	Industrial	650 V	40 A	1.50 V	116A	352 W	44nC	80µA	TO247-3	Yes	Available
A5D20PS065AN	Gen 5	Industrial	650 V	20 A	1.45 V	43A	166 W	42nC	50µA	TO247-2	Yes	Available
ACD20PD065B	Gen 3	Industrial	650 V	20 A	1.45 V	64A	188 W	23nC	80µA	TO247-3	Yes	Available
ACD20PS065C	Gen 3	Industrial	650 V	20 A	1.50 V	58A	176 W	44nC	80µA	TO220-2	Yes	Available
A3D30PB065BN	Gen 3	Industrial	650 V	30 A	1.45 V	80A (per leg/per device)	376 W	34nC	80µA	TO247-3	Yes	Available
ACD20PS065A	Gen 3	Industrial	650 V	20 A	1.50 V	55A	176 W	44nC	80µA	TO247-2	Yes	Available
A5D40PB065BN	Gen 5	Industrial	650 V	40 A	1.45 V	86A (per leg/per device)	332 W	42nC	50µA	TO247-3	Yes	Available
A3D40PB065BN	Gen 3	Industrial	650 V	40 A	1.45 V	80A (per leg/per device)	376 W	34nC	80µA	TO247-3	Yes	Available
A5D06PS065NN	Gen 5	Industrial	650 V	6 A	1.45 V	15A	60 W	14nC	30µA	DFN 5x6	Yes	Available
A3D30HB065BN	Gen 3	Industrial	650 V	30 A	1.30 V	106A (per leg/per device)	246 W	44nC	80µA	TO247-3	Yes	Available
ACD10HS065C	Gen 3	Industrial	650 V	10 A	1.25 V	37A	136 W	34nC	80µA	TO220-2	Yes	Available

Part Number

Data Sheet

Generation

Qualification

V_DC

I_F(T_C=150℃)

V_F (T_J=25℃) Typical

Maximum continuous Current

Total Power Dissipation

Total Capacitive Charge

I_R(T_J=25℃) Max

Package

Recommended
for
New Design?

Release Schedule

A4D50PS120AN

Gen 4

Industrial

1200 V

50 A

TBD

TO247-2

Yes

2024Q1

A3D20PS170AN

Gen 3

Industrial

1700 V

20 A

1.45 V

54A

333 W

200nC

150µA

TO247-2

Yes

Available

A3D30PD170AN

Gen 3

Industrial

1700 V

30 A

1.50 V

74A

455 W

275nC

150µA

TO247-2

Yes

Available

A3D20PA120AN

Gen 3

Industrial

1200 V

20 A

1.40 V

58A

250 W

93nC

200µA

TO247-2

Yes

Available

ACD20PS120A

Gen 3

Industrial

1200 V

20 A

1.45 V

58A

250 W

93nC

200µA

TO247-2

Yes

Available

A3D30PA120AN

Gen 3

Industrial

1200 V

30 A

1.40 V

80A

405 W

152nC

200µA

TO247-2

Yes

Available

ACD20PS120ANX

Gen 3

Industrial

1200 V

20 A

1.45 V

58A

250 W

93nC

200µA

TO247-2

Yes

Available

ACD30PS120ANX

Gen 3

Industrial

1200 V

30 A

1.45 V

80A

330 W

158nC

200µA

TO247-2

Yes

Available

ACD30PS120A

Gen 3

Industrial

1200 V

30 A

1.45 V

80A

330 W

158nC

200µA

TO247-2

Yes

Available

A3D40PB120AN

Gen 3

Industrial

1200 V

40 A

1.45 V

115A

536 W

93nC

200µA

TO247-2

Yes

Available

ACD40PD120B

Gen 3

Industrial

1200 V

40 A

1.45 V

110A
(per leg/per device)

430 W

93nC

200µA

TO247-3

Yes

Available

A3D40PB120BN

Gen 3

Industrial

1200 V

40 A

1.45 V

110A
(per leg/per device)

577 W

93nC

200µA

TO247-3

Yes

Available

ACD50PD120A

Gen 3

Industrial

1200 V

50 A

1.40 V

155A

625 W

310nC

200µA

TO247-2

Yes

Available

A3D20PS120ANB

Gen 3+

Industrial

1200 V

20 A

1.35 V

58A

250 W

93nC

200µA

TO247-2

Yes

Available

A3D20PA120ANB

Gen 3+

Industrial

1200 V

20 A

1.35 V

58A

250 W

93nC

200µA

TO247-2

Yes

Available

A3D30PS120ANB

Gen 3

Industrial

1200 V

30 A

1.35 V

80A

330 W

135nC

200µA

TO247-2

Yes

Available

A3D30PA120ANB

Gen 3

Industrial

1200 V

30 A

1.35 V

80A

330 W

135nC

200µA

TO247-2

Yes

Available

ACD30PS090A

Gen 3

Industrial

900 V

30 A

1.45 V

80A

200 W

101nC

150µA

TO247-2

Available

A3D42PA090AN

Gen 3

Industrial

900 V

42 A

1.40 V

105A

250 W

145nC

150µA

TO247-2

Yes

Available

ACD06PS065G

Gen 3

Industrial

650 V

6 A

1.45 V

18A

68 W

15nC

80µA

DFN 8x8

Yes

Available

ACD06PS065E

Gen 3

Industrial

650 V

6 A

1.45 V

18A

68 W

15nC

80µA

TO263-2

Yes

Available

A3D04PS065NN

Gen 3

Industrial

650 V

4 A

1.40 V

11A

47 W

11nC

80µA

DFN 5x6

Yes

Available

ACD06PS065T

Gen 3

Industrial

650 V

6 A

1.45 V

18A

68 W

15nC

80µA

TO220F

Yes

Available

ACD06PS065N

Gen 3

Industrial

650 V

6 A

1.45 V

18A

68 W

15nC

80µA

DFN 5x6

Yes

Available

ACD10PS065E

Gen 3

Industrial

650 V

10 A

1.45 V

32A

94 W

23nC

80µA

TO263-2

Yes

Available

ACD10PS065C

Gen 3

Industrial

650 V

10 A

1.45 V

32A

94 W

23nC

80µA

TO220-2

Yes

Available

A5D20PS065CN

Gen 5

Industrial

650 V

20 A

1.45 V

43A

166 W

42nC

50µA

TO220-2

Yes

Available

ACD04HS065F

Gen 3

Industrial

650 V

4 A

1.25 V

20A

65 W

15nC

80µA

TO252-2

Yes

Available

ACD04PS065G

Gen 3

Industrial

650 V

4 A

1.40 V

11A

47 W

11nC

80µA

DFN 8x8

Yes

Available

A5D10PS065CN

Gen 5

Industrial

650 V

10 A

1.45 V

23A

100 W

21nC

50µA

TO220-2

Yes

Available

ACD10PS065G

Gen 3

Industrial

650 V

10 A

1.45 V

32A

94 W

23nC

80µA

DFN 8x8

Yes

Available

A5D06PS065FN

Gen 5

Industrial

650 V

6 A

1.45 V

15A

60 W

14nC

30µA

TO252-2

Yes

Available

A5D10PS065TN

Gen 5

Industrial

650 V

10 A

1.45 V

23A

100 W

21nC

50µA

TO220F

Yes

Available

ACD10PS065T

Gen 3

Industrial

650 V

10 A

1.45 V

32A

94 W

23nC

80µA

TO220F

Yes

Available

A5D06PS065CN

Gen 5

Industrial

650 V

6 A

1.45 V

15A

60 W

14nC

30µA

TO220-2

Yes

Available

A5D06PS065TN

Gen 5

Industrial

650 V

6 A

1.45 V

15A

60 W

14nC

30µA

TO220F

Yes

Available

ACD06PS065F

Gen 3

Industrial

650 V

6 A

1.45 V

18A

68 W

15nC

80µA

TO252-2

Yes

Available

A5D08HS065CN

Gen 5

Industrial

650 V

8 A

1.35 V

23A

100 W

21nC

30µA

TO220-2

Yes

Available

A3D08HS065C

Gen 3

Industrial

650 V

8 A

1.35 V

32A

94 W

23nC

80µA

TO220-2

Yes

Available

ACD08PS065C

Gen 3

Industrial

650 V

8 A

1.40 V

32A

94 W

23nC

80µA

TO220-2

Yes

Available

ACD15PS065C

Gen 3

Industrial

650 V

15 A

1.45 V

37A

136 W

34nC

80µA

TO220-2

Yes

Available

A5D10PS065AN

Gen 5

Industrial

650 V

10 A

1.45 V

23A

100 W

21nC

50µA

TO247-2

Yes

Available

A5D10PS065EN

Gen 5

Industrial

650 V

10 A

1.45 V

23A

100 W

21nC

50µA

TO263-2

Yes

Available

A5D10PS065FN

Gen 5

Industrial

650 V

10 A

1.45 V

23A

100 W

21nC

50µA

TO252-2

Yes

Available

ACD06PS065C

Gen 3

Industrial

650 V

6 A

1.45 V

18A

68 W

15nC

80µA

TO220-2

Yes

Available

ACD40PS065A

Gen 3

Industrial

650 V

40 A

1.45 V

80A

250 W

85nC

80µA

TO247-2

Yes

Available

ACD10PS065F

Gen 3

Industrial

650 V

10 A

1.45 V

32A

94 W

23nC

80µA

TO252-2

Yes

Available

ACD10PS065A

Gen 3

Industrial

650 V

10 A

1.45 V

32A

94 W

23nC

80µA

TO247-2

Yes

Available

A5D20PD065BN

Gen 5

Industrial

650 V

20 A

1.45 V

46A
(per leg/per device)

200 W

21nC

50µA

TO247-3

Yes

Available

A5D40PD065BN

Gen 5

Industrial

650 V

40 A

1.45 V

86A
(per leg/per device)

332 W

42nC

50µA

TO247-3

Yes

Available

ACD10HS065A

Gen 3

Industrial

650 V

10 A

1.25 V

37A

136 W

34nC

80µA

TO247-2

Yes

Available

ACD20HD065B

Gen 3

Industrial

650 V

20 A

1.25 V

70A
(per leg/per device)

230 W

34nC

80µA

TO247-3

Yes

Available

ACD40PD065B

Gen 3

Industrial

650 V

40 A

1.50 V

116A

352 W

44nC

80µA

TO247-3

Yes

Available

A5D20PS065AN

Gen 5

Industrial

650 V

20 A

1.45 V

43A

166 W

42nC

50µA

TO247-2

Yes

Available

ACD20PD065B

Gen 3

Industrial

650 V

20 A

1.45 V

64A

188 W

23nC

80µA

TO247-3

Yes

Available

ACD20PS065C

Gen 3

Industrial

650 V

20 A

1.50 V

58A

176 W

44nC

80µA

TO220-2

Yes

Available

A3D30PB065BN

Gen 3

Industrial

650 V

30 A

1.45 V

80A
(per leg/per device)

376 W

34nC

80µA

TO247-3

Yes

Available

ACD20PS065A

Gen 3

Industrial

650 V

20 A

1.50 V

55A

176 W

44nC

80µA

TO247-2

Yes

Available

A5D40PB065BN

Gen 5

Industrial

650 V

40 A

1.45 V

86A
(per leg/per device)

332 W

42nC

50µA

TO247-3

Yes

Available

A3D40PB065BN

Gen 3

Industrial

650 V

40 A

1.45 V

80A
(per leg/per device)

376 W

34nC

80µA

TO247-3

Yes

Available

A5D06PS065NN

Gen 5

Industrial

650 V

6 A

1.45 V

15A

60 W

14nC

30µA

DFN 5x6

Yes

Available

A3D30HB065BN

Gen 3

Industrial

650 V

30 A

1.30 V

106A
(per leg/per device)

246 W

44nC

80µA

TO247-3

Yes

Available

ACD10HS065C

Gen 3

Industrial

650 V

10 A

1.25 V

37A

136 W

34nC

80µA

TO220-2

Yes

Available

飞锃半导体亮相2024国际太阳能光伏展：引领智慧能源新时代的创新产品与解决方案

2024年6月13日至15日，万众瞩目的第十七届（2024）国际太阳能光伏与智慧能源（上海）大会暨展览会成功落下帷幕，为全球能源技术的未来描绘了激动人心的蓝图。在这场汇聚行业精英的盛会上，飞锃半导体以...

新能源汽车

直流充电桩

光伏和储能

不间断电源

碳化硅二极管

碳化硅二极管

飞锃半导体：站在碳化硅风口浪尖引领功率电子器件开发

飞锃半导体闪耀慕尼黑上海电子展，Gen3B碳化硅MOSFET 引领智慧能源新时代

飞锃半导体荣膺“2023汽车电子科学技术奖突出创新产品奖”，引领汽车电子高质量发展

飞锃半导体亮相2024国际太阳能光伏展：引领智慧能源新时代的创新产品与解决方案

需要更多碳化硅产品资料?

点击咨询专家。
